Description
- DLAB Mini H100 Mini Dry Bath
- Mini, lightweight, safe with LCD display
- Digital control over both temperature and time
- Built-in user recalibration function guarantees long term temperature accuracy
- Overheating protection
- Optional cooling function
- Interchangeable blocks for a wide variety of test tube sizes
| Description | Specification / Details |
|---|---|
| Model / Typical Cat.No. | Mini H100 (common Cat.No.: 5042101111 or 5042101111 series) |
| Temperature Setting Range | 25–100 °C |
| Temperature Control Range | Room temperature +5 °C to 100 °C |
| Temperature Control Accuracy | ±0.5 °C |
| Temperature Uniformity | ±0.5 °C (across block) |
| Temperature Display | LCD (shows set and actual temperature + time) |
| Temperature Increment | 0.1 °C |
| Heating Rate | Max. ≈6.5–8 °C/min (25 °C to 100 °C in ≤20 min) |
| Timer Function | Yes |
| Time Setting Range | 0–999 min / 0–999 sec |
| Program Memory | Not standard (some variants support simple programs) |
| Heating Block Material | Aluminum alloy (high thermal conductivity) |
| Block Compatibility | Interchangeable blocks (sold separately or in kits) |
| Common Block Options | 0.2 mL × 40, 0.5 mL × 32, 1.5/2.0 mL × 15, 5 mL × 12, 15 mL × 8, 50 mL × 4, custom sizes available |
| Power Supply | 100–240 V, 50/60 Hz (universal) or DC 12 V (car adapter option) |
| Power Consumption | ≈60–80 W (low power, energy-efficient) |
| Dimensions (W × D × H) | ≈110 × 162 × 140 mm (very compact) |
| Weight | ≤1 kg (ultra-lightweight and portable) |
| Permissible Ambient Temperature | +10–40 °C (or 5–40 °C in some listings) |
| Permissible Ambient Humidity | ≤80% RH |
| Protection Class | IP21 |
| Advanced Features | Lightweight & portable design; LCD display for temp/time; Overheating protection; Rapid calibration function; Optional car power adapter (12 V); Safe & stable for long-term use; USB data export in some variants DLAB Mini H100 Mini Dry Bath |
