Description
| Model | MS-H-PRO＋ |
| Plate dimension | Φ135mm x 135mm (5 inch) |
| Plate material | stainless steel cover with ceramic |
| Motor Type | Brushless DC motor |
| Motor rating input | 18W |
| Motor rating output | 10W |
| Power | 550W |
| Heating power | 500W |
| Voltage | 100 – 120 / 200 – 240 V; 50Hz / 60Hz |
| Stirring positions | 1 |
| Max. stirring quantity of single position (H2O) | 20L |
| Max. magnetic bar | 80mm |
| Speed range | 100-1500rpm resolution ±1rpm |
| Speed display | LCD |
| Temperature display | LCD |
| Temperature range | Room temp.-340°C, increment 1°C |
| Over temperature protection | 420°C |
| Temperature display accuracy | ±0.1°C |
| Temperature control accuracy | ±1°C (<100°C) ±1% (>100°C) |
| External temp. sensor | PT1000 (accuracy ±0.2) |
| Data port | RS232 |
| IP Protection class | IP42 |
| Dimensions[WxDxH] | 160×280×85mm |
| Weight | 2.8kg |
| Permissible ambient temperature | 5～40°C |
| Permissible relative humidity | 80%RH |
