Description
- DLAB OS20-Pro Overhead Stirrer
- Stirring paddle “top- cross” design, easy to replace the container
- LCD display of set and actual speed, torque
- Spillage and overload protection safety circuits
- Brushless DC motor for long life, maintenance free
- Self – locking drill chuck, tools free
- Start/run smoothly, prevent sample splatter or overflow
- Constant speed despite viscosity change of the sample
- Silicone cover protecting drill chuck from erosive vapor
| Description | Specification / Details |
|---|---|
| Cat.No. / Model | 8033100100 / OS20-Pro (LCD Digital Overhead Stirrer) |
| Max. Stirring Quantity (H₂O) | 20 L |
| Speed Range | 50–2200 rpm |
| Speed Display Accuracy | ±3 rpm |
| Max. Torque | 40 N·cm |
| Maximum Viscosity | 10,000 mPa·s (10,000 cP) |
| Motor Type | Brushless DC motor (maintenance-free, high efficiency) |
| Speed Display | LCD |
| Torque Display | LCD (real-time torque monitoring) |
| Overload Protection Display | LCD (visual overload warning) |
| Data Interface | RS232 (for PC connection / data logging) |
| Chuck Clamp Range Diameter | 0.5–10 mm (keyless chuck) |
| Protection Class | IP21 |
| Motor Input Power | 60 W |
| Motor Output Power | 50 W |
| Total Power Consumption | 70 W |
| Voltage / Frequency | 100–240 V, 50/60 Hz (universal power supply) |
| Dimensions (W × H × D) | 83 × 220 × 186 mm |
| Weight | 2.8 kg |
| Permissible Ambient Temperature | 5–40 °C |
| Permissible Ambient Humidity | ≤80% RH |
| Advanced Features | Brushless DC motor, real-time torque display, constant speed under load, overload & over-current protection, keyless chuck, RS232 interface, compact design, quiet operation, anti-stall safety DLAB OS20-Pro Overhead Stirrer |
