Description
-
DLAB OS20-S Overhead Stirrer
- High reliability and outstanding performance
- Wide range of speed from 50 to 2200rpm
- Brushless DC motor for long life, maintenance free and explosion proof
- LED screen for monitoring actual speed
- Safety circuits allow for safe stop function in anti-stall or overload conditions
- Large chuck diameter for many shaft types
| Description | Specification / Details |
|---|---|
| Cat.No. / Model | 8033100200 / DLAB OS20-S LED Overhead Stirrer |
| Max. Stirring Quantity (H₂O) | 20 L |
| Speed Range | 50–2200 rpm |
| Speed Display Accuracy | ±3 rpm |
| Max. Torque | 40 N·cm |
| Maximum Viscosity | 10,000 mPa·s (10,000 cP) |
| Motor Type | Brushless DC motor (maintenance-free, long life, low noise) |
| Speed Display | LED |
| Overload Protection | Yes (electronic protection with LED indicator) |
| Torque / Overload Display | – (LED model shows overload warning; no real-time torque display) |
| Data Interface | – (no RS232 on LED version; available on Pro/LCD models) |
| Chuck Clamp Range Diameter | 0.5–10 mm (keyless chuck) |
| Protection Class | IP21 |
| Motor Input Power | 60 W |
| Motor Output Power | 50 W |
| Total Power Consumption | 70 W |
| Voltage / Frequency | 100–240 V, 50/60 Hz (universal power supply) |
| Dimensions (W × H × D) | 83 × 220 × 186 mm (very compact) |
| Weight | 2.8 kg (lightweight & portable) |
| Permissible Ambient Temperature | 5–40 °C |
| Permissible Ambient Humidity | ≤80% RH |
| Advanced Features | Brushless DC motor; Constant speed under load; Overload & over-current protection; Keyless chuck for quick impeller change; LED display for speed & status; Explosion-proof design features; Quiet operation; Anti-stall safety stop
DLAB OS20-S Overhead Stirrer |
