Description
Specifications
| AC measurement method | True RMS |
| Core jaw diameter | φ33 mm (1.30″), jaw thickness: 8.3 mm (0.33″) |
| Max. rated voltage to earth | Jaw : CAT IV 300 V, CAT III 600 V Voltage measurement terminal : CAT III 300 V, CAT II 600 V |
| AC Current | 42.00 A/ 420.0 A/ 1000 A (±1.5% rdg.±5 dgt.) |
| Frequency characteristics | 40 Hz to 1 kHz |
| AC Voltage | 4.200 V to 600 V, 4 ranges (±1.8% rdg.±7 dgt.) |
| Frequency characteristics | 45 Hz to 500 Hz |
| DC Voltage | 420.0 mV to 600 V, 5 ranges (±1.0% rdg.±3 dgt.) |
| Resistance | 420.0 Ω to 42.00 MΩ, 6 ranges (±2.0% rdg.±4 dgt.) |
| Continuity Check | 420.0 Ω (±2.0% rdg.±4 dgt.) Threshold of buzzer sound 50 Ω±40 Ω or less |
| Crest factor | For 2500 counts or less 2.5, Linearity reduced to 1.5 or less at 4200 counts |
| Display refresh rate | 400 ms |
| Operating temperature and humidity | −25°C to 65°C (−13°F to 149°F), 80% RH or less (no condensation) |
| Storage temperature and humidity | −25°C to 65°C (−13°F to 149°F), 80% RH or less (no condensation) |
| Drop-proof distance | 1 m onto concrete |
| Standards | Safety : EN 61010, EMC : EN 61326 |
| Functions | Data hold, Auto power-saving function |
| Power supply | Coin type lithium battery CR2032×1 |
| Continuous use | 70 hours |
| Dimensions and mass | 57W×181H×16D mm (2.24″W × 7.13″H × 0.63″D), 100 g (3.5 oz.) |
