Description
The INSIZE 1143-200A for precise measurement of depths in narrow grooves, small holes, recesses, bores, slots, and hard-to-reach areas. It features a pointed tip (approximately 1.5mm diameter) on a narrow blade for accessing tight or small-diameter features where standard flat or hook bases cannot reach effectively—ideal for machining, mold making, quality inspection, tool & die work, automotive parts, and precision manufacturing flat or hook gauges fall short. With a 0-200mm/0-8″ range, 0.01mm/0.0005″ resolution, and ±0.03mm (±0.0012″ to ±0.0015″ per sources) accuracy, its pointed tip (~1.5mm) on a narrow blade probes small holes, slots, narrow grooves, recesses, and bores effectively. Built from stainless steel for durability
| Feature | Description |
|---|---|
| Range | 0-200 mm / 0-8″ |
| Resolution | 0.01 mm / 0.0005″ |
| Accuracy | ±0.03 mm (±0.0012″) or ±0.038 mm (±0.0015″) – sources vary slightly, meets general precision standards |
| Material | Stainless steel (blade and main body; hardened for durability) |
| Display | Large digital LCD readout |
| Buttons/Functions | On/Off, Zero (preset), mm/inch conversion (some list On/Off, Set, Preset +/-) |
| Power | CR2032 battery (included); automatic power off, motion-activated power-on (move the unit to wake it) |
| Additional Features | Data output (SPC compatible); pointed tip (~1.5 mm diameter); non-waterproof; full base (~100 mm length) |
| Optional Accessory | Data output cable (codes: 7306-20, 7302-SPC1A/SPC1B, 7305-SPC2) |
