Description
Dlab MS-H-ProT Magnetic Hotplate Stirrer with Timer
| Parameter | Specification |
|---|---|
| Cat.No. | 8030201110 |
| Work plate Dimension | Ø135 mm (5 inch) |
| Work plate material | Stainless steel cover with ceramic coating |
| Max. stirring quantity [H2O] | 20 L |
| Speed range | 100–1500 rpm (resolution ±1 rpm) |
| Speed display | LCD |
| Temperature display | LCD |
| Heating temperature range | Room Temp. – 340℃ (increment 1℃) |
| Temperature control accuracy | ±1℃ (<100℃) / ±1% (>100℃) |
| Temperature display accuracy | ±0.1℃ |
| External temperature sensor | PT1000 (accuracy ±0.2℃) |
| “Hot” warning | 50℃ |
| Overheating temperature protection | 420℃ |
| Motor type | Brushless DC motor |
| Stirring positions | 1 |
| Max. magnetic bar length | 80 mm |
| Data connector | RS232 |
| Timer function | 1 min – 99 h 59 min |
| Protection class | IP21 |
| Motor rating input | 18 W |
| Motor rating output | 10 W |
| Power | 550 W |
| Heating output | 500 W |
| Voltage, Frequency | 100–120 V / 200–240 V，50/60 Hz |
| Dimension [WxDxH] | 160 × 280 × 100 mm |
| Weight | 2.8 kg |
| Permissible ambient temperature | 5–40℃ |
| Permissible ambient humidity | 80% RH Dlab MS-H-ProT Magnetic Hotplate Stirrer with Timer |
