Description
Cat.No.: 8030201110
Work plate Dimension: Ø135mm（5 inch）
Work plate material: stainless steel cover with ceramic coating
Max. stirring quantity [H2O]: 20L
Speed range: 100-1500rpm resolution ±1rpm
Speed display: LCD
Temperature display: LCD
Heating temperature range: Room Temp.-340℃, increment 1℃
Temperature control accuracy: ±1℃(<100℃) ±1%(>100℃)
Temperature display accuracy: ±0.1℃
External temperature sensor: PT1000 (accuracy ±0.2℃)
“Hot” warning: 50℃
Overheating temperature protection: 420℃
Motor type: Brushless DC motor
Stirring positions: 1
Max. magnetic bar length: 80mm
Data connector: RS232
Timer function: 1min-99h59min
Protection class: IP21
Motor rating input: 18W
Motor rating output: 10W
Power: 550W
Heating output: 500W
Voltage,Frequency: 100-120V/200-240V，50/60Hz
Dimension [WxDxH]: 160x280x100mm
Weight: 2.8kg
Permissible ambient temperature: 5-40℃
Permissible ambient humidity: 80% RH
