Description
Lutron AH-4223 Anemometer 4 in 1 (Humidity/Temperature and Dew point)
- Anemometer, Humidity, Temperature meter, 4 in one,professional.
- Humidity with Dew point measurement.
- Vane anemometer, available for wind speed measurement, high reliability.
- Fast response time for humidity measurement.
- Microprocessor circuit ensures high accuracy and provides special functions and features.
- Records Maximum and Minimum readings with recall.
- Auto power off saves battery life.
- Durable, long-lasting components, enclosed in strong, compact ABS-plastic housing.
- Bright LCD display.
Air velocity: 0.4 to 30.0 m/s, ft/min., km/h, mile/h, knots.
Humidity: 10% to 95% RH, Dew.
Temperature: 0 to 50 oC, oC/oF.
Type: hand held type.
Probe: only anemometer.
Record: min.
Battery: DC 1.5V (UM-4, AAA) x 4
Electrical specification
Anemometer (Air velocity)
| Measurement | Range | Resolution | Accuracy |
| m/S | 0.4 to 30.0 m/s | 0.1 m/S | ± 3% F.S. (≤ 20 m/s) ± 4% F.S. (> 20 m/s) |
| Km/h | 1.4 to 108.0 km/h | 0.1 Km/h | |
| FPM | 80 to 5910 ft/min | 1 Ft/min | |
| mph | 0.9 to 67.0 mile/h | 0.1 Mile/h | |
| Knot | 0.8 to 58.3 knots | 0.1 Knots |
Temperature
| Range | 0 to 50ºC |
| Resolution | 0.1ºC |
| Accuracy | ± 0.8ºC |
Humidity
| Range | 10 to 95% RH |
| Resolution | 0.1% RH |
| Accuracy | ± (3% reading + 1% RH) ≥ 70% RH, |
Dew point
| Range | -25.3 to 48.9ºC |
| Resolution | 0.01ºC |
|
|
General specification
| Display | LCD size: 28 x 19 mm. | |
| Circuit | Custom one-chip of microprocessor LSI circuit | |
| Sensor | Anemometer | Van probe with low friction ball bearing design |
| Humidity | Capacitance humidity sensor, semiconductor | |
| Temperature | Semiconductor | |
| Power requirement | Battery AAA x 4 | |
| Dimensions/ Weight | 205 x 48 x 40 mm/ 182 g | |
