Description
-
Introduction K Type Digital Thermometer
The TES-1310 K Type Digital Thermometer delivers accurate and fast temperature measurements across an exceptional range of -50°C to 1300°C, making it one of the most capable handheld thermometers available in Bangladesh today. This thermometer accepts a single K-type thermocouple input and displays readings on a clear 3-1/2 digit LCD with 0.1° resolution. Moreover, it supports T1 and T2 dual-point display along with T1-T2 differential measurement, giving users critical data in a single reading. In addition, the data hold function and °C/°F toggle make this K type digital thermometer practical for both field use and laboratory environments.
Specifications K Type Digital Thermometer
| Model | TES-1310 |
| Sensor Type | K Type Thermocouple |
| Input | Single input |
| Measuring Range | -50°C to 1300°C / -50°F to 1999°F |
| Resolution | 0.1°C / 0.1°F (-50 to 199.9°C/°F) | 1°C / 1°F (others) |
| Accuracy (°C) | ±(0.2% rdg + 1°C) from -50 to 199.9°C | ±(0.3% rdg + 1°C) from -50 to 1000°C | ±(0.5% rdg + 1°C) from 1000 to 1300°C |
| Accuracy (°F) | ±(0.2% rdg + 1°F) from -50 to 199.9°F | ±(0.3% rdg + 2°F) from -50 to 1999°F |
| Accuracy Condition | Mainframe only at 23°C ± 5°C |
| Display | 3-1/2 digit LCD |
| Functions | Data Hold, °C/°F selection, 0.1°/1° resolution selection, T1 & T2 dual display, T1-T2 differential measurement |
| Overrange Indicator | 1—— |
| Low Battery Indicator | BT symbol |
| Input Protection | 60V DC or 24Vrms AC max on any input connector combination |
| Sampling Rate | 2.5 times/sec |
| Operating Condition | 0°C to 50°C (32°F to 122°F), 0–90% R.H. (0–35°C) |
| Power Source | One 9V battery |
| Dimensions | 135mm (L) × 72mm (W) × 31mm (H) |
| Weight | 157g |
| Accessories | Battery and instruction manual not included |
Technical Speciation Summary
| Temperature Range | -50°C to 1300°C | -50°F to 1999°F |
| Best Resolution | 0.1°C / 0.1°F |
| Best Accuracy | ±(0.2% rdg + 1°C) |
| Sensor | K Type Thermocouple |
| Sampling Speed | 2.5 readings/second |
| Display Type | 3-1/2 digit LCD |
| Power | 9V battery |
| Device Weight | 157g (lightweight handheld) |
Key Features
- Wide -50°C to 1300°C measuring range covers both sub-zero and high-heat industrial applications
- K type thermocouple sensor provides fast, reliable temperature response across the full range
- T1 and T2 dual-point display allows simultaneous monitoring of two temperature references
- T1-T2 differential measurement calculates the temperature difference between two points instantly
- Data Hold function freezes the display so users can record readings without looking at the meter
- Selectable 0.1° and 1° resolution lets users choose between precision and readability
- °C/°F toggle switch supports both metric and imperial temperature units
- Compact 157g design makes it easy to carry and use in field and workshop environments
- Input protection up to 60V DC / 24Vrms AC guards the meter against accidental voltage contact
Applications
- Industrial furnace, kiln, and oven temperature monitoring in manufacturing facilities
- HVAC system inspection and air duct temperature profiling
- Food processing and cold chain temperature verification at critical control points
- Automotive engine, exhaust, and radiator temperature diagnostics
- Laboratory and research experiments requiring high-accuracy thermocouple measurements
- Electrical panel and motor thermal monitoring in industrial maintenance
- Plastic and rubber molding process temperature control and verification
- Refrigeration and cold storage facility temperature compliance testing
Who Uses This
- Industrial maintenance engineers who monitor furnace, kiln, and process equipment temperatures
- HVAC technicians performing system commissioning and air temperature profiling
- Food safety officers and quality control inspectors verifying cold chain compliance
- Automotive technicians diagnosing engine and exhaust system heat levels
- Laboratory technicians and researchers conducting thermocouple-based experiments
- Electrical engineers checking motor and panel thermal conditions during maintenance
- Garment and textile factory engineers monitoring dyeing and finishing process temperatures
Frequently Asked Questions (FAQ)
Q1. What is a K type digital thermometer and what does it measure?
A K type digital thermometer uses a K-type thermocouple sensor to measure temperature across a very wide range. The TES-1310 measures from -50°C to 1300°C, making it suitable for both sub-zero refrigeration and high-temperature industrial processes.
Q2. What is the accuracy of the TES-1310 thermometer?
The TES-1310 achieves ±(0.2% rdg + 1°C) accuracy in the -50°C to 199.9°C range. Furthermore, it maintains ±(0.3% rdg + 1°C) accuracy up to 1000°C and ±(0.5% rdg + 1°C) up to 1300°C. These values apply to the mainframe at 23°C ± 5°C ambient temperature.
Q3. Can the TES-1310 measure two temperature points at the same time?
Yes. The TES-1310 supports T1 and T2 dual-point display. Additionally, it calculates the T1-T2 differential measurement automatically, so users can see the temperature difference between two points on a single screen.
Q4. Does the TES-1310 support both Celsius and Fahrenheit?
Yes. Users can switch between °C and °F at any time using the unit selection function. The Fahrenheit range extends from -50°F to 1999°F, which covers the same physical temperature range as the Celsius scale.
Q5. What type of battery does the TES-1310 use?
The TES-1310 runs on a single standard 9V battery. However, the battery is not included in the package, so users need to purchase one separately before first use.
Q6. Where can I buy the TES-1310 K type digital thermometer in Bangladesh?
ASTZ BD stocks the TES-1310 and delivers across Bangladesh. You can place an order directly through our website or contact our team for bulk pricing, technical queries, or product demonstrations.
