SH Scientific SH-DO-550FG Forced Convection Drying Oven Korea

Description

Forced Convection Drying Oven



Locking door handle for minimum heat leakage

Internal observation is possible through the viewing window

Stainless Steel Internal Chamber with shelves

Excellent temperature uniformity and accuracy

Durable structure against continuous operation

Safety assurance with C.E conformity



Specification



Model: SH-DO-550FG

Air Circulation type:  Forced

Temp Range:  Ambient +10℃ to 220℃ (Ambient +18℉ to 428℉)

Time Range: 00.00 to 99HR 59MIN (MIN SEC) Selectable Digital Counter Timer

Temp & Time controller: Micro process PID Membrane Touch Digital controller

Heater Capacity: 4800 W

Dimension Internal: 700×650×1200mm 27.56×25.59×47.24”

Dimension External (W×D×H): 900x950x1610mm 35.43×37.40×63.38′

Weight: 185 kg

Capacity: 546 L

Material Internal: Stainless Steel

Material External: Steel Plate with Powder Heating Coated

Shelves: 2 Supplied (38 Maximum)

Fan Position: Rear

Electrical Requirements 120V, 50/60Hz, 1Φ: 43.6 A

Cat. No.: DO550FG120

Electrical Requirements 230V,50/60Hz, 1Φ: 20.9 A





• Accessory

-Movable stainless wire shelves 2EA





• Option

-Programmable controller

-Digital recorder

-2CH Hybrid recorder

-RS-485 interface

-RS-232C interface





• Safety Device

-Automatic reset function incoming power cut

-Buzzer on when set time arrived

-Door open alarm

-Electric leakage breaker

-Over temp function

-Fire safety controller
