Introduction SOKKIA 0-30 mm Offset Big Prism

The SOKKIA 0-30 mm Offset big Prism for Total Station stands as one of the most trusted reflector solutions in the professional surveying industry. Total station instruments require a high-quality prism to reflect the electromagnetic distance measurement (EDM) signal back to the instrument with minimal deviation, and the precision of that reflection directly determines the accuracy of every distance and coordinate measurement the instrument records.

This SOKKIA 0-30 mm Offset Red Prism Full Set serves surveyors across Bangladesh who work on road alignment, cadastral surveys, building construction layout, river crossing surveys, earthwork volumetric calculations, and infrastructure design. The 0-30 mm offset configuration makes this prism exceptionally versatile: surveyors set the offset to 0 mm when they mount the prism directly on a tribrach over a known point, and they switch to 30 mm when they use a standard prism pole where the physical tip sits 30 mm below the prism optical center.

Specifications SOKKIA 0-30 mm Offset Big Prism

Parameter	Specification
Brand	SOKKIA (Topcon Group)
Model / Set Name	0-30 mm Offset Big Prism Full Set
Prism Type	Circular glass retroreflector prism
Prism Offset	0 mm and 30 mm (switchable)
Prism Constant	0 mm / –30 mm (instrument-dependent)
Prism Diameter	Approx. 62 mm circular aperture
Prism Glass Material	Optical-grade borosilicate glass
Reflective Coating	Factory-applied multi-layer reflective coating
Frame Colour	Red anodised aluminium
Tribrach Mount Thread	International standard 5/8″ × 11 TPI
Instrument Compatibility	SOKKIA SET / CX / iX / SX series; Leica, Topcon, Nikon (standard circular prism mount)
Target Plate	Reflective circular target included
Carrying Case	Hard-shell padded case with foam insert
Kit Contents	Prism with holder, tribrach adapter, mini pole, target plate, carrying case, hex key
Operating Temperature	–20°C to +50°C
Storage Temperature	–30°C to +70°C
Surface Finish	Anodised aluminium body, corrosion resistant
Weight (complete set)	Approx. 0.8–1.2 kg (with case)
Standard Reference	Compatible with ISO 17123-5 total station measurement standards
Warranty	Manufacturer warranty — contact ASTZ for details
